Video Input |
IP Camera Input | 8 Channel |
Incoming Bandwidth | 56 Mbps |
Outgoing Bandwidth | 56 Mbps |
Video Output |
HDMI Output | 3840×2160,1920×1080, 1440×900, 1280×1024 |
VGA Output | 1920×1080, 1440×900, 1280×1024 |
Decoding Capacity | 1ch 8MP, 4ch 1080P, 8ch D1@30fps |
Dual Stream | Support |
Multi-screen Display | 1/4/8/9 |
Recoding |
Resolution | 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 720P, D1 etc. |
Recording Mode | Manual, Schedule (Regular, Continuous), Event |
Trigger Events | Motion Detection, Video Loss, Alarm in, IVS |
Playback and Backup |
Sync Playback | 9/4/1 |
Search Mode | Time /Date, Alarm, Picture grid, Event |
Backup Mode | USB Device, Network |
Alarm |
General Alarm | Motion Detection, Video Loss, Alarm in, Alarm out, IVS (by camera) |
Abnormal Alarm | Disk Alarm, IP Address Conflict, Network Disconnect |
Intelligent Analysis | Intrusion (support the accurate detection of vehicle and human) |
Network |
Interface | 1 RJ-45 port (10/100 Mbps) |
PoE | 8 Ports (IEEE 802.3af), 48W |
Network Function | HTTP, HTTPS, TCP/IP, IPv4, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, P2P, IP Filter, DDNS, 802.1X, SNMP, 3G/4G, PPPoE |
Remote Users | 8 users |
Smart Phone | iPhone, iPad, Android |
Interoperability | ONVIF, SDK, CGI |
)
)
)
